DS0 H1

LácteosCarniceríaCharcuteríaFruterías

Data sheet

Installation Manual

2D CAD

3D CAD

Exploded view

Energy Efficiency Class *

* The information regarding the energy class (according to EU Regulations 2019/2018 and 2019/2024) refers to the best configuration available for these models. Any configuration different from the same can vary significantly in the information related to the energy class. Additionally, this configuration is based on information available at the time of publication of this page. For more information, consult the EPREL European Database of Energy Labeling Products or contact our Commercial Department.

Description

Model Length (mm) Length (with sides) (mm) Refrigerated Shelves Area (m2) Refrigerated Shelves Area (m 2 ) Total Exhibition Area (TDA) (m2) Total Exhibition Area (TDA)(m 2 ) Net Volume (l) Net Volume (l) Shelves (Units) Shelves (units) Doors (Units) Doors (units) Cooling Power (W) Cooling Power (W) Rated Consumption (W) Rated Consumption (W) Refrigerant Refrigerant
DS0 06 H1 685 0.81 0.80 204 3 - 1192 1382 R-290
DS0 09 H1 998 1.21 1.20 306 3 - 1528 1713 R-290
DS0 12 H1 1310 1.61 1.60 408 3 - 1931 1885 R-290
DS0 15 H1 1623 2.02 2.00 510 6 - 2384 2368 R-290
DS0 18 H1 1935 2.42 2.40 612 6 - 3056 3026 R-290
DS0 25 H1 2560 3.23 3.20 816 6 - 3862 3770 R-290

Product Details
