VE-9-C

CharcuteríaCarniceríaLácteos

Our family of 800-depth refrigerated display cases (VE-8) is specially designed to keep dairy products, meat, cured meats, sausages and prepared products in optimal conditions. With an operating range between +1º C to +5º C, it is available in various lengths and with two types of glass: straight or curved.

All the showcases of the VE-8 family can be decorated in a wide range of finishes and colors and can be customized by adding accessories such as plexi closure, curtain closure or extra lighting. We can also manufacture them as neutral showcases.

The VE-8 showcases can be joined together, thus adapting to the specific exhibition space of each client.

Description

Model Length (mm) Length (mm) Height (mm) Height (mm) Depth (mm) Depth (mm) Exhibition Area (m2) Exhibition area (m 2 ) Total Exhibition Area (TDA) (m2) Total Exhibition Area (TDA)(m 2 ) EV chamber (m3) EV camera Doors (Units) Doors (Units) Cooling Power (W) Cooling Power (W) Rated Consumption (W) Rated Consumption (W) Refrigerant Refrigerant
VE-9-10-C 1055 1235 940 0.78 0.62 0.33 1 483 829 R-290
VE-9-13-C 1305 1235 940 0.98 0.78 0.43 two 572 891 R-290
VE-9-15-C 1525 1235 940 1.15 0.92 0.49 two 781 1045 R-290
VE-9-20-C 2025 1235 940 1.55 1.24 0.67 3 949 1133 R-290
VE-9-25-C 2525 1235 940 1.95 1.56 0.84 4 1419 1333 R-290
VE-9-30-C 2995 1235 940 2.33 1.86 1.19 4 1419 1357 R-290

Product Details
